Round fast aluminum melting furnace

Specification Project Specification 3t 5t 6t 8t 10 12t 15t 20t 25t Fixed Capacity(t) 3 5 6 8 10 12 15 20 25 Max Capacity(t) 3.4 5.6 6.7 8.9 11.2 13.5 16.7 22 27.5 Speed of Melting(h/furnace) ≤2.0 ≤2.0 ≤2.5 ≤2.5 ≤2.5 ≤3 ≤3 ≤3.5 ≤3.5 Max melting efficiency(t/h) 1.8 3.2 4 4.8 5.5 6.5 8.5 10 12 Energy Spending(104kcal/t) ≤60 ≤55 ≤55 ≤55 ≤55 ≤50 ≤50 ≤48 ≤48 Efficiency of Burning Da(%) ≤1.5% ≤1.35% Mending Age (n) Vertical furnace ≥2 Bottom furnace≥4 Class of out of smoke Class 1 for Gelinman Common smoke out tem.(°C) ≤150-200 The Highest Tem. of furnace inner(°C) 1150 Burning machine equipped(104kcal/t) 2-45 2-60 2-100 2-100 2-100 2-100 2-160 160+100+100 Center distance(L) 728 940 1023 1088 1216 1357 1538 1775 2036 V F slanting(L1) 100 122 123 112 150 162 200 200 200 Height of total(H1) 2423 2570 2570 2630 2765 3035 3132 3290 3420 Furnace door size(A1×B1) 420×310 600×380 780×550 Basic size(A) 2950 3700 3850 4100 4450 4800 5200 5850 6400 Body weight(t) 35 52 60 64 76 80 102 124 148 Proper fuel kind Light diesel oil,poor diesel oil,coal tarrosin oil,leavings oil,crude oil,natural gas,gas,liquid of gas oil .
